UP26-99SFC 1/6HP 115 SS FLNG MNT PUMP

PART GRU 98961763

SUPPLIER Grundfos

SUPPLIER PART # 98961763

Calculating price...

QUANTITY

About this item

Grundfos, 98961763, Circulator Pump, Canned Rotor, Series: UPS, 17.6 gpm Flow Rate, 28.87 ft Maximum Head, 197 W Power, 115 V AC, 1.3 to 1.8 A, 60 Hz Frequency, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Ceramic Radial/Carbon Thrust Bearing, 6 in W x 6-1/2 in H Dimensions

UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.

CSA Certified|UL Listed

Amperage Rating 1.3 to 1.8 A

Bearing Type Ceramic Radial/Carbon Thrust

Dimensions 6 in W x 6-1/2 in H

Flow Rate 17.6 gpm

Frequency Rating 60 Hz

Impeller Type Composite PES

Maximum Head 28.87 ft

Maximum Pressure 145 psi

Phase 1

Power Rating 197 W

Series UPS

Temperature Rating 140 deg F

Type Canned Rotor

Voltage Rating 115 V AC

Brand Grundfos

Maintenance-free

Low noise and low energy

Complete range and wide range of accessories

Stainless steel rotor can and bearing plate

Corrosion-resistant impeller

No additional motor protection is required

Non-electronically controlled circulator pumps for domestic building with speed control

Flange pipe connection

Stainless steel pump housing

Large stator

3-speed motor

Catalog

Specification Sheet

Instruction/Installation Manual
