UPS15-58FRC .04HP 115V 3SPD FLNG MNT CI CIRC

PART GRU 59896343

SUPPLIER Grundfos

SUPPLIER PART # 59896343

Calculating price...

QUANTITY

About this item

Grundfos Circulator Pump, Series: UPS, 17.2 gpm, 19.36 ft Maximum Head, 87 W, 115 V AC, 0.55 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, 2450 rpm Motor, 104 deg F, 5-1/4 in W x 6-1/2 in H

The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. The pump has 3-step speed selector.

CSA Certified|UL Listed

Amperage Rating 0.55 to 0.75 A

Dimensions 5-1/4 in W x 6-1/2 in H

Flow Rate 17.2 gpm

Frequency Rating 60 Hz

Maximum Head 19.36 ft

Maximum Pressure 145 psi

Motor Speed 2450 rpm

Phase 1

Power Rating 87 W

Series UPS

Temperature Rating 104 deg F

Voltage Rating 115 V AC

Brand Grundfos

Ceramic shaft and radial bearings

Carbon axial bearing

Stainless steel rotor can and bearing plate

Corrosion resistant impeller, composite, PES

Cast iron pump housing

1 ph motor, no additional motor protection is required

Specification Sheet

UPS15-58FRC .04HP 115V 3SPD FLNG MNT CI CIRC
