UP15-18B5 1/25HP 115 BRZ 1/2SWT MNT PUMP

PART GRU 59896114
SUPPLIER Grundfos
SUPPLIER PART # 59896114
Calculating price...
QUANTITY

About this item

Grundfos, 59896114, Circulator Pump, Canned Rotor, Series: UP Series, 4.75 gpm Flow Rate, 1/2 in C Inlet, 1/2 in C Outlet, 13.78 ft Maximum Head, 85 W Power, 115 V AC, 0.74 A, 60 Hz Frequency, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Radial/Thrust Bearing, 4-11/16 in W x 5 in H Dimensions

The Grundfos circulator pumps, Series UP are specifically designed for heating systems. The pumps are also suitable for circulation of hot domestic water and for circulation of liquid in cooling and air conditioning systems.

CSA Certified|UL Listed
Amperage Rating 0.74 A
Bearing Type Radial/Thrust
Dimensions 4-11/16 in W x 5 in H
Flow Rate 4.75 gpm
Frequency Rating 60 Hz
Impeller Type Composite PES
Inlet Size 1/2 in C
Maximum Head 13.78 ft
Maximum Pressure 145 psi
Outlet Size 1/2 in C
Phase 1
Power Rating 85 W
Series UP Series
Temperature Rating 140 deg F
Type Canned Rotor
Voltage Rating 115 V AC
Brand Grundfos
  • Ceramic shaft, radial bearings and carbon thrust bearing
  • Stainless steel rotor can and bearing plate
  • Impeller of corrosion-resistant material
  • No additional motor protection is required
  • Non-electronically controlled circulator pumps for domestic building with speed control
  • Bronze pump housing
  • Small stator
  • 1-speed motor
