Home Valves & Actuators Shut-Off Valves Gas Shut-Off Valves 1 MAIN BURNER GAS VLV 1/8 NPT TAP

1 MAIN BURNER GAS VLV 1/8 NPT TAP

PART CONB 50-403-02
SUPPLIER Apollo™
SUPPLIER PART # 5040302
Calculating price...
QUANTITY

About this item

Apollo™, 5040302, Main Control Valve, Manual, Series: 50, 1 in Nominal, FNPT End Style, 10 psi Pressure, 32 to 125 deg F, Lever Handle Actuator, 3.94 in Inlet to Outlet Length, 2.19 in Top to Inlet Center, Bronze Body, Stainless Steel Trim, 3.87 in H Dimensions, Domestic

ANSI Z21.15, CGA 9.1|cCSAus Certified|PROP65: Cancer and Reproductive Harm
Actuator Type Lever Handle
Body Material Bronze
Dimensions 3.87 in H
Domestic/Import Domestic
End Style FNPT
Inlet to Outlet Length 3.94 in
Nominal Size 1 in
Pressure Rating 10 psi
Series 50
Temperature Rating 32 to 125 deg F
Top to Inlet Center 2.19 in
Trim Material Stainless Steel
Type Manual
Brand Apollo™
Country of Origin US
Warranty 5 Years
  • Factory tested 100% at 10 psig
  • Capacity to 2100000 Btu/hr
  • Bosses on both sides are drilled and tapped, only one side is plugged
  • 1/8 in NPT pilot handle position X
