127T GLOBE VLV 300# BRZ BRZ SEAT 1' NPT

PART CONB 33-665-01
SUPPLIER Apollo™
SUPPLIER PART # 3366501
Calculating price...
QUANTITY

About this item

Apollo™, 3366501, Globe Valve, Series: 127T, 1 in Nominal, NPT End Style, 1000 psi CWP Pressure, 300 lb Pressure Class, -20 to 422 deg F, 12.1 gpm Flow Rate, Handwheel Actuator, 6.71 in Open Top to Inlet Center, Bronze Body, Brass/Bronze Trim, Graphite/Grafoil Softgoods, 4 in L Dimensions, Domestic

The Apollo™ Model 127T (33-66x Series) Globe Valve provides a cost effective Made in the USA alternative to globally sourced multi-turn valves. These heavy duty valves are cast, machined, assembled, and tested in South Carolina. Apollo™ globe valves are ideal for steam and liquid service and can reliably be installed in most plumbing and heating systems including building service piping and OEM applications.

ARRA Compliant|ASME B1.20.1|ASTM B21 UNS C46400 Stem|ASTM B61 Body/Disc/Seat|CRN 0C14667.5|MSS SP-80|PROP65: Cancer and Reproductive Harm
Actuator Type Handwheel
Body Material Bronze
Dimensions 4 in L
Domestic/Import Domestic
End Style NPT
Flow Rate 12.1 gpm
Nominal Size 1 in
Pressure Class 300 lb
Pressure Rating 1000 psi CWP
Series 127T
Softgoods Material Graphite/Grafoil
Temperature Rating -20 to 422 deg F
Top to Inlet Center 6.71 in Open
Trim Material Brass/Bronze
Brand Apollo™
Country of Origin US
Warranty 5 Years
  • Rising stem
  • Union bonnet
  • Bronze disc with back seat protection
  • Dezincification resistant bronze construction
  • Rugged malleable iron hand wheel
  • Optimum flow capacity
  • 100% factory tested to MSS SP-80
  • Bronze seat and disc/brass stem
