Home Water Heaters Commercial Commercial Gas Tank Water Heaters 75 GAL GAS COMM WTR HTR DHH-72-1/8:D-28-1/4

75 GAL GAS COMM WTR HTR DHH-72-1/8:D-28-1/4

PART BWC D-75T-125-3N
SUPPLIER Bradford White®
SUPPLIER PART # D75T1253N
Calculating price...
QUANTITY

About this item

Bradford White® Gas Water Heater, Flue Damper, 125000 Btu/hr Heating, Natural Gas, 3/4 in Gas Connection, 75 gal Tank, Electronic Ignition, Atmospheric Vent, 5 in Vent Size, 303 gph at 40 deg F Rise Recovery, 80 % Energy Efficient, 1-1/2 in Water Connection, 150 psi, 180 deg F, Ultra Low NOx: No, ASME Yes/No: No, Steel, Vitraglas®, 28-1/4 in Dia x 32-1/2 in D x 72-1/4 in H, Domestic

Bradford White 75 Gallon Commercial Gas (Natural) Atmospheric Vent Water Heater with Flue Damper and Electronic Ignition. 3-Year Tank Warranty, 125,000 BTU/Hr., 120 Volts, Single Phase, with Power Cord included.

AHRI Certified|ANSI Z-21.10.3|ASME HLW Standard|ASHRAE 90.1b|CSA LLC-Low Lead Content|CSA International (Formerly AGA/CGA)|CEC Listed|NSF Approved|North Carolina Code Compliant|PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov
ASME Yes/No No
Dimensions 28-1/4 in Dia x 32-1/2 in D x 72-1/4 in H
Domestic/Import Domestic
Energy Efficiency 80 %
Finish Vitraglas®
Fuel Type Natural Gas
Gas Connection 3/4 in
Heating Capacity 125000 Btu/hr
Ignition Type Electronic
Material Steel
Pressure Rating 150 psi
Recovery Rate 303 gph at 40 deg F Rise
Tank Capacity 75 gal
Temperature Rating 180 deg F
Type Flue Damper
Ultra Low NOx No
Vent Size 5 in
Vent Type Atmospheric
Water Connection 1-1/2 in
Brand Bradford White®
Country of Origin US
Warranty 3 Years Limited on Tank/1 Year Limited on Component Parts
  • ICON HD™ - Intelligent proven design combines temperature control, diagnostic codes and system ignition functions into a single control board with a digital LCD display
  • Operation mode - Two different digitally displayed operation modes have the capability of adjusting the temperature setting up to 180 deg F, and adjusting the degree setting
  • Service mode - Eight different digitally displayed service modes can be easily cycled through by pressing the select button
  • Electronic ignition - High voltage, low current electricity is sent to the pilot electrode initiating a spark to ignite the pilot gas
  • Automatic flue damper
  • Factory installed Hydrojet® sediment reduction system - Cold water inlet sediment reducing device helps prevent sediment build up in the tank
  • Vitraglas® lining
  • Insulation system - Non-CFC foam covers the sides and top of the tank, reducing heat loss
  • Water connections - 3/4 in NPT factory installed true dielectric fittings extend water heater life and simplify water line connections
  • Hand hole cleanout
  • E.C.O - An automatic re-set energy cut off (E.C.O.) shuts off all gas in event of an overheat condition
  • Protective magnesium anode rod
  • Sanitizing capability
